Improve Your Audio Workflow with the Vibration 45’ Audio Production & Multitrack Truck

The Vibration 45’ Audio Production & Multitrack Truck is a top-tier mobile audio control room built to handle the most demanding broadcast, concert, and recording needs. Operated by TNDV, a division of Live Media Group Holdings, Vibration provides studio-grade 5.1 surround mixing, expansive multitrack recording options, and dual mix booths. This compact yet powerful setup allows you to capture and produce high-quality audio for anything from music festivals and sports events to corporate productions, all while on the move.

Measuring 45 feet long, 14 feet wide when expanded, and 13.5 feet high, Vibration has a gross vehicle weight of 67,000 pounds. Its power requirements are 3 Phase at 150 Amps and 208 Volts, with 100 feet of feeder cable and camlock connectors included. The truck’s configuration maximizes interior space for engineers, producers, and talent, creating a comfortable environment that supports seamless production workflows.

At the heart of Vibration is a Studer Vista 9 Digital Mixing Console offering 62 faders, 344 DSP inputs, and full 5.1 surround sound capabilities. It supports 96×48 analog, 64×64 AES, and 256×256 MADI channels, and can connect to up to four 64×32 fiber stageboxes (with two already onboard). For multitrack recording, Vibration features two Avid Pro Tools rigs that each support up to 128 channels, as well as four JoeCo Black Box recorders that each handle 64 channels. A Waves SuperRack Server with Mercury Bundle support further enhances processing and mixing options. Monitoring and conversion are handled by Fostex speakers, plus SDI-HDMI converters, Fiber Rattler sets, and Decimator MD-Cross Converters to ensure clear, accurate audio in any scenario.

Vibration includes dual control booths designed for simultaneous dual mixes, such as front-of-house and broadcast, or for other specialized purposes like production management or on-the-fly video coordination. The truck also comes with multiple fly-pack systems that enable hybrid production setups, supporting both audio and video needs within one cohesive operation. For recording workflows, Vibration houses an AJA KiPro HDD Recorder and a total of 12 recording channels through the combined KiPros and JoeCo units, allowing you to capture, archive, and synchronize audio across digital and analog signal paths.

To match the console’s professional mixing capabilities, Vibration carries a robust microphone inventory. It includes eight Sennheiser shotgun microphones, four Telefunken M80 handheld mics, two Audio-Technica wired lavaliers, two Audio-Technica AT2021 condensers, two AKG C214 condensers, two Audio-Technica BP4073 shotguns, two Audio-Technica AT4022 condensers, and two Mojave MA-101 condensers. These options allow you to cover everything from ambient crowd sounds to precise vocal capture for on-stage performances or interviews.

A reliable communication infrastructure is crucial for smooth productions. That’s why Vibration is equipped with an RTS Zeus 24-Port Digital Matrix, four RTS PL channels, two RTS telephone interfaces, and two Biscuit Boxes, ensuring everyone from the engineering crew to on-air talent stays in sync. For routing and signal conversion, the truck includes a 32×32 AJA Kumo Video Router, a 3×3 audio embed/de-embed unit, two DirectOut Andiamo2.XT analog/AES-to-MADI converters, one DirectOut M.1k2 16-port MADI router, and two AJA FS1x MADI sample rate converters. These components maintain signal integrity and proper synchronization in complex audio environments.

Vibration’s extensive cable inventory supports flexible event layouts. It carries 2250 feet of DT-12 cable, plus a 1000-foot and a 500-foot TAC-12 fiber mult. This allows for extended runs, remote I/O setups, and multi-location coverage without sacrificing signal quality. By bringing together broadcast-ready 5.1 surround sound, high-capacity multitrack recording, and a carefully designed control space, Vibration stands out as a flagship mobile audio unit for live music festivals, major TV specials, sports productions, and beyond. It operates like a full-fledged studio but travels as easily as a standard truck, offering a turnkey solution that can adapt to nearly any live or recorded production scenario.

Vibration is ideal for music and concert recordings, immersive live network broadcasts, remote multitrack sessions that feed into post-production, and a variety of special events or corporate AV setups. In every application, it delivers clarity, power, and reliable performance. For more details or to book the Vibration 45’ Audio Production & Multitrack Truck, contact TNDV at 877-959-8638 or reach out via contact@tndv.com.
