Vibration 45’ Audio Production & Multitrack Overview

The Vibration 45’ Audio Production & Multitrack Truck is a premium mobile audio control room designed to meet the most demanding broadcast, concert, and recording needs. Outfitted with a world-class audio console, dual mix booths, and multitrack recording capabilities, Vibration delivers pristine 5.1 surround sound and unmatched flexibility for both live and post-production applications. Operated by TNDV, a division of Live Media Group, this mobile unit is built for high-end audio capture, broadcast-quality sound, and scalable, studio-grade multitrack sessions on the go.

Dimensions and Configuration

Vibration is a 45-foot mobile expando unit purpose-built for high-performance audio workflows.

• Length: 45 ft
• Width: 14 ft (expanded)
• Height: 13.5 ft
• Gross Vehicle Weight: 67,000 lbs
• Power: 3 Phase, 150 Amps, 208 Volts (3 hot legs, 1 ground — no neutral required)
• Feeder Cable: 100 ft with camlock connectors

Audio Facilities

At the core of Vibration is the Studer Vista 9 Digital Mixing Console, engineered for high-end mixing in demanding environments.

• 62 faders and 344 DSP inputs
• Full 5.1 surround sound mixing capabilities
• Channel Support:
  • 96×48 Analog
  • 64×64 AES
  • 256×256 MADI
• Wired for up to 4 64×32 Fiber Stageboxes (2 included onboard)

Multitrack Recording Systems Include:

• (2) Avid Pro Tools 128-Channel Audio Recording Rigs
• (4) JoeCo Black Box 64-Channel Audio Recorders
• (1) Waves SuperRack Server with Mercury Bundle Support

Monitoring and Conversion Equipment:

• (2) Fostex Speakers
• (4) SDI-HDMI Converters
• (4) Fiber Rattler Sets
• (2) Decimator MD-Cross Converters

Vibration’s audio suite is engineered for top-tier mixing and mastering in real time or post-event scenarios.

Production and Control Spaces

Vibration includes dual control booths—one primary and one secondary—which can be configured for:

• Simultaneous dual audio mixes (e.g., FOH + broadcast)
• Dedicated video production
• Production management or talent coordination

Vibration can also be equipped with multiple fly-pack systems for hybrid production environments and flex spaces, giving teams the flexibility to handle both audio and video workflows simultaneously.

Recording Capabilities

The audio truck is equipped with:

• (1) AJA KiPro HDD Recorder
• 12 total recording channels via KiPros and JoeCo units
• Seamless integration with digital and analog signal paths ensures synchronization, archiving, and post-event delivery options.

Microphone Inventory

Vibration includes a broad and professional-grade microphone package:

• (8) Sennheiser Shotgun Microphones
• (4) Telefunken M80 Handheld Mics
• (2) Audio-Technica Wired Lavaliers
• (2) Audio-Technica AT2021 Condenser Mics
• (2) AKG C214 Condenser Mics
• (2) Audio-Technica BP4073 Shotgun Mics
• (2) Audio-Technica AT4022 Condenser Mics
• (2) Mojave MA-101 Condenser Mics

This array provides full coverage for stage, field, crowd, studio, or ambient capture.

Communications Infrastructure

Built for professional communication in live production environments, Vibration is equipped with:

• RTS Zeus 24-Port Digital Matrix
• (4) RTS PL Channels
• (2) RTS Telephone Interfaces
• (2) Biscuit Boxes

This setup enables seamless, real-time communication between crew, talent, and engineering teams across production zones.

Terminal Equipment

Robust I/O and routing hardware ensure scalable and adaptable workflows:

• 32×32 AJA Kumo Video Router
• 3×3 Audio Embed/De-Embed Unit
• (2) DirectOut Andiamo2.XT Analog/AES to MADI Converters
• (1) DirectOut M.1k2 16-Port MADI Router
• (2) AJA FS1x MADI Sample Rate Converters

This equipment supports routing, conversion, synchronization, and signal integrity in any environment.

Cable Inventory

Vibration comes with an extensive cable inventory to meet the needs of complex event layouts:

• 2250’ DT-12 Cable
• (1) 1000’ TAC-12 Fiber Mult
• (1) 500’ TAC-12 Fiber Mult

This ensures optimal connectivity for long cable runs, remote I/O setups, and multi-venue coverage.

Why Vibration Stands Out

Vibration is a flagship mobile audio control unit—combining broadcast-ready surround sound, massive multitrack capability, and modular control spaces. Its integrated fly-pack systems, world-class microphones, and flexible routing architecture make it an ideal choice for:

• Live music festivals
• Network-level TV specials
• Sports productions requiring complex audio capture
• Remote recording sessions and award shows

It’s a turnkey solution that performs like a studio, moves like a truck, and delivers like a broadcast giant.

Applications

Vibration is ideal for:

• Music and concert recordings
• Live network broadcasts with surround audio
• Remote audio multitrack for post-production
• Special events, worship, and corporate AV audio capture

Technical Specifications

Conclusion

The Vibration 45’ Audio Production & Multitrack Truck offers one of the most comprehensive mobile audio environments in the industry. Whether you’re producing a Grammy-level music event, a live-streamed worship service, or a sports broadcast with immersive surround sound, Vibration gives you the flexibility, power, and quality to meet any challenge.

For bookings and availability, contact TNDV at 877-959-8638 or contact@tndv.com.

Equipment complement is subject to change to accommodate specific needs.
