Switcher: Grass Valley 3G K-Frame – 5 M/E 125×56
Audio Board: Calrec Artemis Beam (96×96 Analog, 64×64 AES, 256×256 MADI)
Router: Evertz EQX 436×472 SDI, 88 3G Framesyncs, 320×38 Multiview
Cameras: Sony HDC4300 UHD/HDR
Replay: EVS XT4K
Flexible UHD-HDR Mobile Unit with Integrated Replay and Broadcast Audio
The MU-18 is a fully equipped 3G mobile production truck designed to deliver exceptional performance across a broad spectrum of live event needs. Combining a 9 M/E switcher, a 72-channel EVS replay environment, and a powerful UHD/HDR camera kit, MU-18 is ideal for national sports, live entertainment, corporate broadcasts, and streaming productions. With a highly capable multiview, 88 frame syncs, and modern surround sound mixing, this unit delivers high-end production value in a scalable format.
Key Specifications
Production Switching
Replay Systems
Routing & Terminal Infrastructure
Evertz EQX 3G video router:
Evertz EMR audio router:
Multiview capacity: 320×38
Frame sync and color processing (88 frame syncs):
Camera System
Lens kit includes:
Wired for 16 cameras. Other camera and lens configurations are available on request.
Audio Facilities
Calrec Artemis Beam digital surround sound console:
Communications
RTS Adam matrix intercom (288×288):
Additional comms inventory:
A/V Support Inventory
Cable Infrastructure
Contact Operations for a specific list.
Why MU-18 Stands Out
MU-18 strikes the perfect balance between performance and footprint. With 9 M/Es of switching, a UHD-HDR camera package, a high-capacity EVS environment, 88 HDR frame syncs, and full multiviewer and routing capabilities, it’s ideal for mid- to large-scale productions where broadcast reliability, quick deployment, and pristine quality are non-negotiable. Its onboard surround sound capabilities and deep connectivity make it a versatile choice for sports, entertainment, corporate, and festival productions.
Ideal Use Cases
Fast Reference Specs
| Category | Specification |
|---|---|
| Video Switcher | GV K-Frame 3G · 9 M/E · 125×56 |
| Replay System | Up to 6× EVS XT-VIA + Spotbox · XFile3 · 72 EVS channels |
| Router | Evertz EQX 3G (436×472) / EMR audio matrix |
| Frame Sync | 88 total · 48 Cobalt 9905-MPx · 40 EVS Neuron |
| Audio Console | Calrec Artemis Beam · 64 faders |
| Camera System | Sony HDC-4300 UHD-HDR · 16 wired · Fujinon glass |
| Comms | RTS Adam 288×288 · PL/IFB/OMNEO/RVON |
| Power | 3-phase · 200 A minimum · 150′ cable |
| Dimensions | 53′ × 8.5′ (road) / 13.5′ (expanded) |
| GVW | 80,000 lbs |
For more information or to book MU-18 for your next major broadcast, contact Live Media at 833.933.5483 or email solutions@livemediagroup.com.
Equipment complement is subject to change to accommodate specific needs.
