Switcher: Grass Valley 3G K-Frame – 7 M/E 128×64
Audio Board: Calrec Apollo (96×96 Analog, 192×192 AES, 512×512 MADI)
Router: NVision NV8576 540×954 SDI, 60 3G Framesyncs, 342×38 Multiview
Cameras: Sony HDC3500 UHD/HDR
Replay: EVS XTVia
MU-15 is a premium mobile broadcast truck engineered for large-scale live productions, UHD and HDR workflows, and multi-camera sports or entertainment events. With a powerful 7 M/E switcher, expansive routing, and robust EVS replay backbone, MU-15 delivers uncompromising performance for both linear broadcast and streaming environments. MU-15 blends flexibility, scalability, and modern signal architecture into a single elite production platform for complex, high-capacity productions.
Video Production Technology
MU-15 is powered by a Grass Valley K-Frame 3G switcher with a Kayenne 4-stripe, 35-button panel, featuring:
Replay and Recording
Camera System
MU-15 is wired for up to 16 CCUs and features:
Audio Capabilities
MU-15 features a Calrec Apollo digital surround sound console:
Routing and Multiview
Grass Valley NV8576 3G video router (540×954 matrix):
Frame sync and multiview:
Communication Infrastructure
MU-15 features an RTS Adam 176×176 matrix intercom system:
A/V Support
Cable Inventory
Contact Operations for a specific list.
Power Requirements
Why MU-15 Stands Out
MU-15 is built for major productions requiring maximum capacity, flexibility, and reliability. With 7 M/Es and 128 switcher inputs, 16-CCU UHD-HDR camera capacity, room for up to six 12-channel EVS servers, a Calrec Apollo console with Waves processing, a 540×954 NV8576 router, and 60 HDR frame syncs including 40 EVS Neuron channels, MU-15 is a complete remote broadcast solution for top-tier sports, network specials, and entertainment events.
Applications
Perfect for:
Technical Specifications
| Category | Details |
|---|---|
| Switcher | GV K-Frame 3G · 7 M/E · 128×64 |
| Cameras | Sony HDC-3500 UHD-HDR · 16 CCUs wired |
| Replay & Playback | Up to 6× EVS XT-VIA 12-ch + 1 Spotbox |
| Audio Console | Calrec Apollo · 48 dual faders |
| Routing | GV NV8576 3G (540×954) |
| Frame Sync | 60 total · 20 For-A HDR · 40 EVS Neuron HDR |
| Multiview | 342×38 |
| Intercom | RTS Adam 176×176 matrix |
| Power | 3-phase · 200 A minimum · 150′ 2/0 AWG |
For more information or to book MU-15 for your next major broadcast, contact Live Media at 833.933.5483 or email solutions@livemediagroup.com.
Equipment complement is subject to change to accommodate specific needs.
