Switcher: Grass Valley K-Frame – 7 M/E 96×48
Audio Board: Calrec Artemis (96×96 Analog, 128×128 AES, 256×256 MADI)
Router: Evertz EQX 280×620 SDI, 70 3G Framesyncs, 304×30 Multiview
Cameras: Grass Valley LDX 86 HDR
Replay: EVS XT3
MU-12 Overview
MU-12 is a broadcast-grade triax mobile production unit built for large-scale, high-profile live events. Outfitted with a 7 M/E Grass Valley K-Frame switcher, a 64-fader Calrec Artemis Beam audio room, Grass Valley LDX 86 triax cameras wired for 16 CCUs, and an Evertz routing core with 40 EVS Neuron HDR frame syncs, MU-12 is ideal for live sports, entertainment broadcasts, award shows, and corporate events. Operated by Live Media, a division of Live Media Group, MU-12 delivers flexibility and performance for complex productions.
Video Production Technology
MU-12 is powered by a Grass Valley K-Frame 3G switcher with a Kayenne 4-stripe, 35-button panel, featuring:
Replay and Recording
Camera System
MU-12 is wired for up to 16 CCUs and features:
Audio Capabilities
MU-12 features a Calrec Artemis Beam digital surround sound console:
Routing and Multiview
Evertz EQX 3G video router (316×322 matrix):
Evertz EMR audio router:
Frame sync, conversion, and multiview:
Communication Infrastructure
MU-12 features an RTS Adam 256×256 matrix intercom system:
A/V Support
Cable Inventory
Contact Operations for a specific list.
Power Requirements
Why MU-12 Stands Out
MU-12 is designed for major productions requiring capacity, flexibility, and reliability. With 7 M/Es of K-Frame switching, 16-CCU camera capacity, a 64-fader Artemis Beam console with Waves processing, a 316×322 Evertz router, and 40 EVS Neuron HDR frame syncs, MU-12 is a complete remote broadcast solution for live sports, network specials, and entertainment events.
Applications
Perfect for:
Technical Specifications
| Category | Details |
|---|---|
| Switcher | GV K-Frame 3G · 7 M/E · 96×48 |
| Cameras | GV LDX 86 WorldCam Triax · 16 CCUs wired |
| Replay & Playback | Up to 3× EVS XT-VIA 12-ch + 1 Spotbox |
| Audio Console | Calrec Artemis Beam · 64 faders |
| Routing | Evertz EQX 3G (316×322) & EMR audio router |
| Frame Sync / Conversion | 40 EVS Neuron HDR · 18 router FS · 4 TX processors |
| Multiview | 304×23 |
| Intercom | RTS Adam 256×256 matrix |
| Power | 3-phase · 208 V · 200 A · 200′ feeder |
For more information or to book MU-12 for your next major broadcast, contact Live Media at 833.933.5483 or email solutions@livemediagroup.com.
Equipment complement is subject to change to accommodate specific needs.
