Switcher: Grass Valley K-Frame – 4.5 M/E 75×48
Audio Board: Calrec Artemis Light (96×96 Analog, 96×96 AES, 192×192 MADI, 64×64 DANTE)
Router: Grass Valley Trinix 288×512 SDI, 20 Framesyncs, 228×19 Multiview
Cameras: Grass Valley LDX 82 Elite
Replay: EVS XT3
MU-10 is a broadcast-grade triax mobile production unit built for high-profile live events. Outfitted with a 4.5 M/E Grass Valley Kayenne switcher, a 56-fader Calrec audio room, Grass Valley LDX 82 triax cameras wired for 16 CCUs, and comprehensive Grass Valley routing, MU-10 is ideal for live sports, entertainment broadcasts, award shows, and corporate events. Operated by Live Media, a division of Live Media Group, MU-10 delivers flexibility and performance for complex productions.
Video Production Technology
MU-10 is powered by a Grass Valley Kayenne Classic switcher, featuring:
Replay and Recording
Camera System
MU-10 is wired for up to 16 CCUs and features:
Audio Capabilities
MU-10 features a Calrec Artemis Light Bluefin 2 digital audio console with Concord:
Routing and Multiview
Grass Valley Trinix video router (288×512 matrix):
Concerto audio router:
Conversion and multiview:
Communication Infrastructure
MU-10 features an RTS Adam 128×128 matrix intercom system:
A/V Support
Power Requirements
Why MU-10 Stands Out
MU-10 is designed for productions requiring flexibility, capacity, and reliability. With 4.5 M/Es of Kayenne switching, 16-CCU camera capacity, a 288×512 Trinix router, 25 channels of For-A conversion, and a 56-fader Calrec console with Waves processing, MU-10 is a complete remote broadcast solution for live sports, network specials, and entertainment events.
Applications
Perfect for:
Technical Specifications
| Category | Details |
|---|---|
| Switcher | GV Kayenne Classic · 4.5 M/E · 75×48 |
| Cameras | GV LDX 82 Triax Elite · 16 CCUs wired |
| Replay & Playback | Up to 3× EVS XT3 12-ch + 4-ch Spotbox |
| Audio Console | Calrec Artemis Light Bluefin 2 w/ Concord · 56 faders |
| Routing | GV Trinix (288×512) & Concerto audio router |
| Conversion | 25 For-A U/D/C frame syncs w/ CC · 3 TX processors |
| Multiview | 228×19 |
| Intercom | RTS Adam 128×128 matrix |
| Power | 3-phase · 208–220 V · 200 A minimum · 150′ 2/0 AWG |
For more information or to book MU-10 for your next broadcast, contact Live Media at 833.933.5483 or email solutions@livemediagroup.com.
Equipment complement is subject to change to accommodate specific needs.
