MU-30 | 46’ 3G Single Expando with C-Band Uplink

Compact Production + Transmission Power for Broadcast-Grade Remote Events

The MU-30 is a fully integrated 3G HD production truck engineered for seamless field broadcasting and live satellite transmission. With a compact single-expando design, this unit combines a Grass Valley K-Frame switcher, powerful Calrec audio, high-end camera package, and built-in 2.4m C-Band uplink antenna. Ideal for sports, live news, public affairs, and events requiring on-site acquisition + transmission, MU-30 delivers studio-grade capabilities in a streamlined footprint.

Vehicle Overview

• Trailer Length: 46’
• Operational Footprint: 21’ W x 13.5’ H
• Overall Length (with Tractor): Approx. 65’
• Deployed Height (with Dish): 22’
• Gross Vehicle Weight (GVW): 80,000 lbs
• Power Requirements:
  • 1 Phase, 200 Amps @ 208 Volts
  • 2 Hot Legs, 1 Ground (No neutral required)
  • 150’ Camlock Feeder Cable

Production System

• Grass Valley K-Frame Production Switcher
  • Kayenne 4-Stripe, 35-Button Panel
  • 5 M/E, 64 Inputs / 48 Outputs
  • FlexiKey™, Double Take, Chroma Key
  • 16 iDPMs and 2D DPM
  • Integrated ImageStore
• Multiview & Monitoring
  • 170×34 Multiviewer Capacity
  • Dedicated monitor wall layouts for TD, Director, Producer, and AD as shown in page 3 visual layout

Record & Playback

• (1) EVS XT3 6-Channel LSM Server
• (1) EVS XT3 6-Channel Spotbox w/ Lance Controller
• (1) EVS X-File3
• Wired for up to (3) EVS servers

Routing & Terminal Infrastructure

• NVision NV8280 3G/HD Video Router (242×360 Matrix)
  • 80×80 Embedding / De-embedding
  • (20) Cobalt 3G UDC Frame Syncs
  • (10) For-A 9600 Frame Syncs w/ Color Correction
  • Image Video TSI-3000 for tally control

Camera System

• (8) Grass Valley LDX80 WorldCam Cameras
• (5) Grass Valley Super XPanders
• (8) LDK4426 Fiber Triax Converters

Lens Package Includes:

• (3) Canon 86×9.3 HD Box Lenses
• (1) Canon 72×9.3 HD Box Lens
• (2) Canon 22×7.6 ENG Zoom Lenses
• (1) Canon 11×4.7 Wide Angle Lens
• Wired for 10 CCUs

Audio Facilities

• Calrec Artemis Bluefin2 Digital Audio Console
  • 48 Faders
  • 240 DSP Channels
  • 96×120 Analog I/O
  • 32×32 AES Digital I/O
  • 320×320 MADI
  • 64×64 DANTE IP

Communications System

• RTS ADAM-M Matrix (166×166 Ports)
  • 16 RVON Channels
  • 64 OMNEO Channels
  • 12 Powered Intercom Channels
  • 12 Powered IFB Channels

Intercom Inventory:

• (11) RTS BP325 Dual Listen Belt Packs
• (9) RTS 4030 IFB Boxes
• (9) Single Muff Headsets
• (3) Dual Muff Headsets
• (4) Telephone Interfaces
• (4) Innkeeper QKT Couplers

A/V Support Inventory

• (5) HMD26 Announcer Headsets
• (5) Studio Tech Announcer Boxes
• (5) MD46 Stick Microphones
• (6) MKH416 Shotgun Microphones
• (6) MKH807 Long Shotgun Microphones
• (4) MKH418 Stereo Shotgun Microphones
• (4) 15” SDI Field Monitors
• (4) 21” SDI Field Monitors
• (2) LED Lighting Kits

Cable Infrastructure

• 7000’ Triax Camera Cable
• 2100’ DT12 Audio Mult
• (1) 1000’ TAC-12 Fiber
• (1) 500’ TAC-4 Fiber
• (6) 100’ 5-Wire Coax Looms
• (1) 100’ 10-Wire Coax Loom

Satellite Uplink Capabilities

• 2.4m AVL C-Band Uplink Antenna (roof-mounted)
• (2) Advantech 300-Watt Hub Mount C-Band SSPBs
• (2) Adtec EN-100 Encoders
• (2) Adtec RD-70 Professional Receivers

This enables on-site contribution, backup feeds, or live distribution directly from the truck — no flypack or auxiliary uplink needed.

Why MU-30 Stands Out

MU-30 is a hybrid powerhouse, purpose-built to serve both production and transmission needs from a single unit. Its small-footprint, single-expando design is ideal for venues with limited space or quick setup demands. Whether for remote news broadcasts, field sports coverage, or special event programming, MU-30 delivers studio-grade switching, audio, camera, and satellite uplink — all from one mobile command center.

Ideal Applications

• Political & Government Event Broadcasts
• Remote News & Public Affairs Uplinks
• Mid-Size Live Sports
• Satellite Backup Feed or Redundant Path Coverage
• Hybrid Live & Transmission Deployments
